Light Source System
Light Source: PhiLIPs MSD Silver 420W.
Color Temperature: 7900K (500K).
Light Source Lifespan: 250,000 hours.
Lens Diameter: 180mm.

Color System
Color Wheel: 14 + seven-color rainbow effect +雾化功能.

Pattern System
1 fixed pattern wheel, 13 patterns + white light, capable of bidirectional variable speed rotation.

Zoom System
Beam Angle: Parallel beam angle 0-2°.

Prisms
Prism 1: 1 piece of 8-prism, with adjustable prism rotation and speed functions. Prism 2: 1 piece of 16-prism, with adjustable prism rotation and speed functions.

Fogging: Built-in fogging mirror can generate and adjust softening effects.

Dimming: 0-100% linear dimming.

Stroboscope
Maximum up to 25Hz, random stroboscope selectable, speed controllable.

Scanning
1 horizontal scanning: 540° (8/16bit precision scanning). Vertical scanning: 270° (8/16bit precision scanning). With automatic error correction and reset function.

Display System
LCD display, 4 touch buttons for function control, display can be flipped 180°, with screen off/lock function, Chinese and English switching.

Protection Class: IP66. Control: 16/20 channel control modes, standard DMX512 protocol. RDM control.

Dimensions and Weight
Product Dimensions: 705*375*340 (unit not specified).
Net Weight: 26kg.

Electrical Parameters
Power Supply: AC100-240V, 50/60Hz.
Total Lamp Power: 600W.
