·Titan windows operating system
• Core I7 6500 CPU, 128G SSD, 8G memory
• One 15.6-inch capacitive touchscreen, one 7-inch capacitive touchscreen
• 6 LCD screens with adjustable brightness
• 40 faders and 20 macro function keys
• 3 independent page-turning systems, each capable of turning 60 pages
• 16 built-in DMX output ports, supporting up to 8,192 channels
• 1 LTC timecode trigger port
• Supports MIDI timecode and SMPTE timecode
• Supports Titan-net protocol, expandable to 64 Universe DMX outputs
• 3 imported metal-shaft optical encoders (for parameter adjustment)
• 4 imported metal-shaft optical encoders with push-function (for playback adjustment)
• 4 built-in Gigabit Ethernet ports, 2 built-in Gigabit fibre ports
• Built-in UPS power supply enabling console startup without 220V AC mains connection
• Network-enabled video server control
• 3 USB ports
• Supports IOS and Android remote control (requires router connection)
• Net weight: 40 kg
• Flight case dimensions: 30*54*114 cm
