Light Source System
19 OSRAM 40W 4-in-1 LED beads
(Red, Green, Blue, White)
Light source lifespan: 50,000 – 100,000 hours.
Dimming: 0~100% linear dimming.
Performance Features
RGBW (Red, Green, Blue, White) linear color mixing, 16.7 million colors (0-100% saturation adjustable), built-in macro functions. Front mirror disc with variable direction and stepless rotation, seamless splicing mirror disc, aspherical lens structure, single bead point control. Light strip effects: stroboscopic, running light effects, with built-in programs. Screen automatic rotation function.
00
Control mode: DMX512 control / manual / automatic.
Built-in CTO DMX linear dimming.
Protection class: IP20.
Channel mode: 21/22/35/36/37CH.
Performance Features
Horizontal scanning: 540 (8/16bit precision scanning).
Vertical scanning: 270 (8/16bit precision scanning).
With automatic error correction reset function.
Electrical Parameters
Rated voltage: AC100~240V 50/
