Light Source System
Light Source: 295W.
Color Temperature: 7900K (±500K).
Light Source Lifespan: 2000 hours.
Lens Diameter: 152mm.

Color System
Color Wheel: 13 colors + white light.

Pattern System
1 fixed pattern wheel with 13 patterns + white light, capable of bidirectional variable speed rotation.

Zoom System
Beam Angle: Parallel beam angle 0-2 degrees.

Focusing System: Electronic focusing.

Prism
Prism: 24-prism + 8-prism, can be overlapped.

Fogging: Built-in fogging mirror can generate and adjust softening effects.

Seven Colors: Built-in seven-color wheel effect.

Dimming: 0-100% linear dimming.

Stroboscope: Up to 25Hz, random strobing selectable, speed adjustable.

Scanning
Horizontal Scanning: 540 degrees (8/16-bit precision scanning).
Vertical Scanning: 270 degrees (8/16-bit precision scanning).
With automatic error correction and reset function.

Intelligent Fan Speed Regulation
When the lamp is not lit, the fan stops running to reduce noise.

Display System
LCD display, 4 touch buttons for function control, display can be flipped 180 degrees, with screen off/lock function, Chinese and English switching.

Protection Class: IP20.

Control: 17-channel control mode, standard DMX512 protocol. RDM control.

Dimensions and Weight
Electrical Parameters
Product Dimensions: 370*260*535mm.
Net Weight: 13.5KG.
Power Supply: AC100-240V, 50/60Hz.
Total Lamp Power: 500W.
