Light Source System
Light Source: PhiLIPs MSD Silver 380W.
Color Temperature: 7900K±500K.
Light Source Lifespan: ≥3000 hours.
Lens Diameter: 138mm.

Color System
Color Wheel: 9 colors + white light.

Pattern System
1 fixed pattern wheel, 13 patterns + white light, bidirectional variable-speed rotation.
CTO adjustable from 3200K to 5600K.

Intelligent Fan Speed Regulation
The fan stops operating when the lamp is off to reduce noise.

Zoom System
Beam Angle: Parallel beam angle 2°–19°.
Pattern Angle: 4.1°–40°.
Atomization Light Angle: 2°–19°.
Focusing System: Electronic focusing.

Prism
Prism: 16-facet prism + 6-row prism, stackable.
Atomization: Built-in atomizing lens for adjustable softening effect.

Dimming: 0–100% linear dimming.
Strobe: Up to 25Hz, random strobe available with adjustable speed.

Scanning
Horizontal Scanning: 540° (8/16-bit precision scanning)
Vertical Scanning: 270° (8/16-bit precision scanning)
With automatic error correction reset function.

Display System: LCD display, 4 touch buttons for functional control; display reversible by 180°, with screen off/lock function and Chinese-English switching.

Protection Grade: IP20.
Control: 20/24-channel control mode, standard DMX512 protocol, RDM control.

Dimensions and Weight
Product Dimensions: 370*260*600mm.
Net Weight: 17.3KG.

Electrical Parameters
Power Supply: AC100–240V, 50/60Hz.
Total Lamp Power: 600W.
