Light Source System
Osram 60W four-in-one lamp beads (red, green, blue, white).
Light source lifespan: 50,000 – 100,000 hours.
Dimming: 0~100% linear dimming.
Performance Features
RGBW (red, green, blue, white) linear color mixing, 16.7 million colors (0-100% saturation adjustable), built-in macro function. Control mode: DMX512 control/manual/automatic.
Protection class: IP65.
Channel mode: 17 channels.
Horizontal scanning: 540 (8/16bit precision scanning).
Vertical scanning: 270 (8/16bit precision scanning).
With automatic error correction reset function.
Electrical Parameters
Rated voltage: AC100~240V 50/60Hz.
Rated power: 500W.
Weight and Dimensions
Product size: 375*319*496mm.
Product weight: 17KG.
