Light Source System
7 40W 4-in-1 LED OSRAM light sources
(red, green, blue, white).
Light source lifespan: 50,000 – 100,000 hours.
Dimming: 0~100% linear dimming.
Performance Features
RGBW (red, green, blue, white) linear color mixing, 16.7 million colors (0-100% saturation adjustable), built-in macro functions.
Front lens disc with variable direction and stepless rotation, seamless splicing lens disc, aspherical lens structure, single lamp bead point control. Light strip effects: stroboscopic, running light effects, with built-in programs. Screen automatic rotation function. 4-45DMX linear focusing, with automatic focusing function. Control modes: DMX512 control / manual / automatic. Built-in CTO DMX linear dimming.
Protection class: IP20.
Channel modes: 21/22/35/36/37CH.
Performance Features
Horizontal scanning: 540 (8/16bit precision scanning).
Vertical scanning: 270 (8/16bit precision scanning). With automatic error correction reset function:
Electrical Parameters
Rated voltage: AC100~240V 50/
