Light Source System
Light source: 295W.
Color temperature: 7900K ± 500K.
Light source lifespan: 2000 hours.
Lens diameter: 128mm.
Color System
Color wheel: 12 colors + white light.
Pattern System
1 fixed pattern wheel, 11 patterns + white light, capable of bidirectional variable speed rotation.
Zoom System
Beam angle: parallel beam angle 0-2 degrees.
Focusing system: electronic focusing.
Dual-ring light strip: (24 + 32) * 0.2W RGB LEDs.
Prism
Prism: 16-prism + 8-prism, can be overlapped.
Fogging: Built-in fogging mirror can generate and adjust softening effects.
Seven colors: Built-in seven-color wheel effect.
Dimming: 0-100% linear dimming.
Stroboscope: Up to 25Hz, random stroboscope can be selected, with controllable speed.
Scanning
Horizontal scanning: 540 degrees (8/16-bit precision scanning).
Vertical scanning: 270 degrees (8/16-bit precision scanning).
With automatic error correction reset function.
Intelligent Fan Speed Regulation
When the lamp is not lit, the fan stops running to reduce noise.
Display System
LCD display, 4 touch buttons for function control, the display can be rotated 180 degrees, with screen off/lock function, and Chinese-English switching.
Protection class: IP20. Control: 25-channel control mode, standard DMX512 protocol. RDM control.
Dimensions and Weight
Electrical Parameters
Product size: 360*189*450mm.
Net weight: 9.3KG.
Power supply: AC100-240V, 50/60Hz.
Total lamp power: 450W.
MINI295 295W Beam Moving Head Light, DMX Stage Beam Spot Lighting Fixture
1. Product Overview
MINI295 beam moving head light adopts 295W high brightness lamp source with 9500K color temperature and 3000-hour service life.
Built-in independent RGB LED ambient wash ring, 12 color wheels + white light, 16-piece rotating prism, adjustable 0–2° narrow beam angle.
It supports 540° horizontal & 270° vertical precise scanning, linear 0–100% dimming and random strobe effects. Standard DMX512 & RDM signal control,
intelligent variable speed silent fan, ideal for small and medium entertainment venues.
2. Core Features
- High Brightness 295W Lamp Source
9500K cool white light, long service life, sharp clear beam output.
- Rich Optical Effects
12 color mixing wheel, 16-facet rotating prism, independent RGB surrounding wash light, built-in fog softening effect.
- Wide Range Precise Scanning
540° horizontal / 270° vertical bidirectional variable speed rotation, 8/16-bit precision scanning.
- Standard Professional Signal Control
25 DMX control channels, compatible DMX512 & RDM protocol, LCD touch screen with Chinese/English switchable menu.
- Low Noise Intelligent Heat Dissipation
Auto-adjust fan speed according to lamp temperature, effectively reduce running noise for indoor venues.
