Light Source System
Light source: 295W.
Color temperature: 7900K ± 500K.
Light source lifespan: 2000 hours.
Lens diameter: 128mm.
Color System
Color wheel: 12 colors + white light.
Pattern System
1 fixed pattern wheel, 11 patterns + white light, capable of bidirectional variable speed rotation.
Zoom System
Beam angle: parallel beam angle 0-2 degrees.
Focusing system: electronic focusing.
Dual-ring light strip: (24 + 32) * 0.2W RGB LEDs.
Prism
Prism: 16-prism + 8-prism, can be overlapped.
Fogging: Built-in fogging mirror can generate and adjust softening effects.
Seven colors: Built-in seven-color wheel effect.
Dimming: 0-100% linear dimming.
Stroboscope: Up to 25Hz, random stroboscope can be selected, with controllable speed.
Scanning
Horizontal scanning: 540 degrees (8/16-bit precision scanning).
Vertical scanning: 270 degrees (8/16-bit precision scanning).
With automatic error correction reset function.
Intelligent Fan Speed Regulation
When the lamp is not lit, the fan stops running to reduce noise.
Display System
LCD display, 4 touch buttons for function control, the display can be rotated 180 degrees, with screen off/lock function, and Chinese-English switching.
Protection class: IP20. Control: 25-channel control mode, standard DMX512 protocol. RDM control.
Dimensions and Weight
Electrical Parameters
Product size: 360*189*450mm.
Net weight: 9.3KG.
Power supply: AC100-240V, 50/60Hz.
Total lamp power: 450W.
